A solid panel facade is cladding made from solid metal sheet — typically 2–4 mm aluminium — folded into trays and fixed to a sub-frame with a ventilated gap behind. It gives a clean, seamless look and protects the building from weather. Unlike composite panels with a plastic core, solid aluminium is non-combustible.
Solid Aluminium 3003-H24 / 5005-H34 · 3 mm standard
Extruded Aluminium Rail System · Ventilated Rainscreen
Concealed Hook-On · A4 Stainless Rivets (exposed option)
Flat · Curved · 3D Folded · Open-Joint
IS 875 Part 3 — project-specific certification
Shop drawings + engineer cert. — no extra cost
Solid aluminium has no polyethylene core, making it a more fire-safe choice for high-rise and public buildings.
Rigid, flat and dent-resistant, with PVDF finishes that hold their colour.
Panels can be folded, curved or formed into 3D shapes.
The ventilated cavity sheds rain and reduces heat build-up.
We plan panel layout, joint lines and fixing details.
Sheets are CNC-cut, folded into trays, stiffened and coated.
Panels hang on a sub-frame with a ventilated air gap, using open or sealed joints.
Clean, monolithic surfaces with crisp joint lines.
Rolled, bent or folded for sculptural forms.
Shadow-gap joints for a refined look.
Combine with perforated panels for screens and vents.
ACP has two thin aluminium skins bonded to a core, often polyethylene. Solid panels are a single sheet of 2–4 mm aluminium — more rigid, non-combustible, fully recyclable and longer-lasting. ACP is usually cheaper.
Aluminium itself is non-combustible, so solid panels avoid the fire risk of plastic-core composites. Overall fire performance also depends on insulation, sub-frame and cavity barriers, so we design the full assembly.
3 mm is the common choice for exterior facades. 2 mm suits smaller panels and soffits. 4 mm suits large panels or high-wind locations.
Yes. Panels can be rolled, bent or folded into curves and 3D shapes.
Correct thickness, rear stiffeners and fixing design keep panels flat and minimise visible waviness (oil-canning). We specify these per panel size.
Our facade specialists respond within one business day with a cost estimate and initial direction.
